Product Summary
The AD9882AKSTZ-100 is a Dual Interface for Flat Panel Displays. The AD9882AKSTZ-100 offers designers the flexibility of an analog interface and a digital visual interface (DVI) receiver integrated on a single chip. Also included is support for high bandwidth digital content protection (HDCP). The applications of the AD9882AKSTZ-100 include RGB graphics processing, LCD monitors and projectors, Plasma display panels, Scan converter, Microdisplays and Digital TV.
Parametrics
AD9882AKSTZ-100 absolute maximum ratings: (1)VD: 3.6 V; (2)VDD: 3.6 V; (3)Analog Inputs: VD to 0.0 V; (4)VREF: VD to 0.0 V; (5)Digital Inputs: 5 V to 0.0 V; (6)Digital Output Current: 20 mA; (7)Operating Temperature: –25 to +85℃; (8)Storage Temperature: –65 to +150℃; (9)Maximum Junction Temperature: 150℃; (10)Maximum Case Temperature: 150℃.
Features
AD9882AKSTZ-100 features: (1)Analog interface; (2)140 MSPS maximum conversion rate; (3)Programmable analog bandwidth; (4)0.5 V to 1.0 V analog input range; (5)500 ps p-p PLL clock jitter at 140 MSPS; (6)3.3 V power supply; (7)Full sync processing; (8)Midscale clamping; (9)4:2:2 output format mode; (10)Digital interface; (11)DVI 1.0 compatible interface; (12)112 MHz operation; (13)High skew tolerance of 1 full input clock; (14)Sync detect for hot plugging; (15)Supports high bandwidth digital content protection.
