Product Summary

The DD28F032SA100 is a 32-Mbit FlashFile memory. It is a revolutionary architecture which enables the design of truly mobile, high performance, personal computing and communication products. With innovative capabilities, low power operation and very high read/program performance, the DD28F032SA100 is also the ideal choice for designing embedded mass storage flash memory systems.

Parametrics

DD28F032SA100 absolute maximum ratings: (1)Temperature Under Bias: 0 to +80℃; (2)Storage Temperature: –65 to +125℃.

Features

DD28F032SA100 features: (1)User-Selectable 3.3V or 5V VCC; (2)User-Configurable ×8 or ×16 Operation; (3)70 ns Maximum Access Time; (4)28.6 MB/sec Burst Write Transfer Rate; (5)1 Million Typical Erase Cycles per Block; (6)56-Lead, 1.2 × 14 × 20 mm Advanced Dual Die TSOP Package Technology; (7)64 Independently Lockable Blocks; (8)Revolutionary Architecture 100% Backwards-Compatible with Intel 28F016SA; (9)2 mA Typical ICC in Static Mode; (10)2 μA Typical Deep Power-Down; (11)State-of-the-Art 0.6 μm ETOX IV Flash Technology.

Diagrams

DD28F032SA100 block diagram
