Product Summary

The EP3C16F484C8N is a lowest power FPGA with security.

Parametrics

EP3C16F484C8N absolute maximum ratings: (1)VCCINT, Supply voltage for internal logic: –0.5 to 1.8 V; (2)VCCIO, Supply voltage for output buffers: –0.5 to 3.9 V; (3)VCCA, Supply voltage (analog) for phase-locked loop (PLL) regulator: –0.5 to 3.75 V; (4)VCCD_PLL, Supply voltage (digital) for PLL: –0.5 to 1.8 V; (5)VI DC, input voltage: –0.5 to 3.95 V; (6)IOUT, DC output current, per pin: –25 to 40 mA; (7)VESDHBM, Electrostatic discharge voltage using the human body model: ±2000 V max; (8)VESDCDM, Electrostatic discharge voltage using the charged device model: ±500 V max; (9)TSTG, Storage temperature: –65 to 150 ℃; (10)TJ, Operating junction temperature: –40 to 125 ℃.

Features

EP3C16F484C8N features: (1)Lowest power consumption due to: TSMC low-power process technology; Altera power-aware design flow; (2)Low-power operation offers the following benefits: Extended battery life for portale and handheld applications; reduced or eliminated cooling system costs; Operation in thermally-challenged environments; (3)Hot-socketing operation support; (4)Configuration security using advanced encryption standard (AES) with 256-bit volatile key; (5)Routing architecture optimized for design separation flow with the QuartusR II software; (6)Design separation flow achieves both physical and functional isolation between design partitions; (7)Ability to disable external JTAG port; (8)Error Detection (ED) Cycle Indicator to core.

Diagrams

EP3C16F484C8N block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
EP3C16F484C8N
EP3C16F484C8N


IC CYCLONE III FPGA 16K 484FBGA

Data Sheet

0-1: $19.92
