TMS320F240PQA

DSP controller, 132-QFP, -0.3V to 7V, TMS320F240PQA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: TMS320F240PQA

Brand:: Texas Instruments - TI | Pack: QFP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Van Dannis's store

(Singapore)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-03

From Other Seller

Part Number:TMS320F240PQA
US $1.00 - 2.00
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320F240PQA is a DSP controller. It is optimized for digital motor/motion control applications. The TMS320F240PQA DSP controller combines the enhanced TMS320 architectural design of the C2xLP core CPU for low-cost, high-performance processing capabilities and several advanced peripherals optimized for motor/motion control applications. The peripherals of the TMS320F240PQA include the event manager module, which provides general-purpose timers and compare registers to generate up to 12 PWM outputs, and a dual10-bit analog-to-digital converter (ADC), which can perform two simultaneous conversions within 6.1 μs.

Parametrics

TMS320F240PQA absolute maximum ratings: (1)Supply voltage range, VDD: -0.3 V to 7 V; (2)Input voltage range: -0.3 V to 7 V; (3)Output voltage range: -0.3 V to 7 V; (4)Operating free-air temperature range, TA: L version: 0 to 70℃; A version: -40℃ to 85℃; S, Q versions: -40℃ to125℃; (5)Storage temperature range, Tstg: 55℃ to 150℃.

Features

TMS320F240PQA features: (1)High-Performance Static CMOS Technology; (2)Dual 10-Bit Analog-to-Digital Conversion Module; (3)28 Individually Programmable, Multiplexed I/O Pins; (4)Phase-Locked-Loop (PLL)-Based Clock Module; (5)Watchdog Timer Module (With Real-Time Interrupt); (6)Serial Communications Interface (SCI) Module; (7)Serial Peripheral Interface (SPI) Module; (8)Six External Interrupts (Power Drive Protect, Reset, NMI, and Three Maskable Interrupts); (9)Four Power-Down Modes for Low-Power Operation; (10)Scan-Based Emulation.
